Air Compressor
A screw air compressor (also known as a rotary screw compressor) is a positive-displacement gas compressor that uses two intermeshing helical rotors—commonly referred to as the male and female rotors—to compress air. Unlike traditional piston compressors that rely on a reciprocating motion, rotary screw compressors use a continuous rotary motion to trap and compress air, delivering a smooth, pulsation-free flow.
Our screw air compressors are engineered with precision-machined screw elements, robust industrial-grade construction, and advanced control systems to deliver reliable, energy-efficient compressed air for a wide range of industrial applications.The self-developed screw rotor with high efficiency and large displacement adopts the self-developed rotor profile, which has a more optimized leakage triangle, shorter contact line and smaller discharge end space than the traditional profile.With precise bearing arrangement to improve rotor rigidity, and optimized oil injecting ratio, Zeding compressors operate with lower noise and less vibration.
Application of Air Compressor
Power Supply: In industries such as machinery manufacturing and power generation, air compressors serve as vital power equipment, supplying energy to pneumatic tools and devices. In mining operations, they provide the necessary power for tasks such as drilling and blasting.
Construction and Mining Sectors: In the construction and mining industries, air compressors power equipment such as water well drills, down-the-hole (DTH) drills, reverse circulation drills, pneumatic picks, and rock drills, thereby enhancing operational efficiency.
Applications in Environmental Protection and Cleaning: In environmental protection projects, the compressed air generated by air compressors can be used for back-blowing in dust removal systems, thereby improving dust collection efficiency.
Technical of Anchor Drilling Rig
| Model | ZD-15/15 | ZD-18/18 | ZD-31/25 | ZD-36/35 |
| Rated FAD | 15m3/min,550CFM | 18m3/min,660CFM | 31m3/min,1137CFM | 36m3/min,1320CFM |
| Rated Pressure | 15Bar,1.5Mpa218PSI | 18Bar,1.8Mpa261PSI | 25Bar,2.5Mpa363PSI | 35Bar,3.5Mpa508PSI |
| Engine Power | 140Kw | 160Kw | 294Kw | 563Kw |
| Air Discharge Valve Size | G1-1/2’’&G1’’ | G1-1/2’’&G1’’ | G1-1/2’’&G1’’ | G2-1/2’’&G1-1/2’’ |
| Dimension | 325*1.61*2.2M | 3.45*1.75*2.29M | 4.18*2.1*2.51M | 5.1*2.23*2.92M |
| Weight | 2520Kg | 3050Kg | 5100Kg | 8500Kg |
